Nondestructive Testing
Supreme NDT provides expert nondestructive testing services to ensure the integrity, safety, and compliance of materials and structures. From advanced inspection methods like Ultrasonic Testing and Radiographic Testing to third-party audits and custom NDT program setups, we deliver tailored solutions to refineries, fabrication shops, and pipeline construction companies’ unique needs. Trust Supreme NDT for reliable results that protect your assets and operations.
Visual testing (VT), also called visual inspection, is a nondestructive testing (NDT) method that visually examines a component to assess the need for maintenance.Visual examiners follow procedures ranging from simply looking at a part to detect surface imperfections to using computer-controlled camera systems to recognize and measure component features automatically. It’s the most common NDT method used across industries and can be used at any stage of a component’s lifecycle. VT is often the first step in examining products like castings, forgings, machined components, and weld elements.
Magnetic particle testing (MT) detects impurities on or just beneath the surface of a workpiece by creating a magnetic field with a permanent magnet or an electromagnet. An electromagnet requires an electric current. Both methods generate magnetic flux lines that change in the presence of impurities. Unfortunately, this is not detectable by the human eye. Therefore, NDT technicians introduce colored magnetic particles in either powder or liquid form. If defects are present, the particles will be drawn to them, enabling the technician to inspect them.It is widely used in weld inspections, forgings, and castings in the oil and gas industry.
Liquid Penetrant Testing (PT) involves coating the test object with a solution that contains either a visible or fluorescent dye. Excess solution is removed from the object’s surface but remains in surface-breaking defects. A developer is then applied to extract the penetrant from these defects. With fluorescent dyes, ultraviolet light makes the bleed-out fluoresce brightly, allowing imperfections to be easily observed.
In Ultrasonic Testing (UT), high-frequency sound waves are transmitted into a material to detect imperfections or identify changes in material properties. The most commonly used ultrasonic testing technique is pulse-echo, where sound is introduced into a test object, and reflections (echoes) from internal imperfections or the object’s geometric surfaces are returned to a receiver. Below is an example of a shear wave weld inspection. Please take a look at the indication extending to the upper limits of the screen; this indication results from sound reflected from a defect within the weld. It is commonly used for weld inspections, thickness measurements, and flaw detection in pipelines and tanks.
Radiographic Testing (RT) involves penetrating gamma or X-radiation on materials and products to identify defects or examine internal or hidden features. An X-ray generator or radioactive isotope serves as the source of radiation. This radiation is directed through a part and onto film or another detector. The resulting shadowgraph illustrates the internal features and soundness of the part. Material thickness and density changes appear as lighter or darker areas on the film or detector. The darker regions in the radiograph below indicate internal voids within the component.
When a solid material is stressed, imperfections emit short bursts of acoustic energy known as “emissions.” Specialized receivers can detect similar to ultrasonic testing, acoustic emissions. Sources of emissions can be evaluated by studying their intensity and arrival time to gather information, such as their location, about the energy sources.
There are several electromagnetic testing methods, but this overview focuses on eddy current testing. In eddy current testing, electrical currents (eddy currents) are created in a conductive material by a changing magnetic field. The strength of these eddy currents can be measured. Material defects interrupt the flow of the eddy currents, alerting the inspector to a defect or other material changes. Eddy currents are also influenced by a material’s electrical conductivity and magnetic permeability, enabling some materials to be sorted based on these properties. The technician in the image is inspecting an aircraft wing for defects.
Various techniques are employed to detect and locate leaks in pressure containment components, vessels, and structures. Leaks can be identified through electronic listening devices, pressure gauge measurements, liquid and gas penetrant methods, or basic soap bubble tests.
